Solid State Relays
About Opto 22 Solid State Relays
In 1974, Opto22 introduced the first liquid epoxy-filled line of power solid-state relays (SSR). This innovation in SSR design greatly improved the reliability and reduced the cost of manufacturing. At that time, they also incorporated 100% testing under full-load conditions of every relay they manufactured.
Opto 22 offers a complete line of SSRs, from the rugged 120/240/380-volt AC Series to the small footprint MP Series, designed for mounting on printed circuit boards. All Opto22 SSRs feature 4,000 volts of optical isolation. All are UL recognized, and most are CSA certified. The innovative use of room-temperature liquid epoxy encapsulation, coupled with Opto22’s unique heat-spreader technology, are key to mass producing the world’s most reliable solid-state relays.
P-Series
P240D4
The P240D4 is a DC-controlled P Series relay that switches 240 VAC at up to 4 A.
P Model, 240 VAC, 4 Amp, DC Control Solid State Relay (SSR)
P120D4
The P120D4 is a DC-controlled P Series relay that switches 120 VAC at up to 4 A.
P Model, 120 VAC, 4 Amp, DC Control Solid State Relay (SSR)
DC60P
The DC60P is a DC-controlled P Series relay that switches 60 VDC at up to 3 A.
P Model, 60 VDC, 3 Amp, DC Control Solid State Relay (SSR)
DC200P
The DC200P is a DC-controlled P Series relay that switches 200 VDC at up to 1 A.
P Model, 200 VDC, 1 Amp, DC Control Solid State Relay (SSR)
MP-Series
MP380D4
The MP380D4 is a DC-controlled MP Series relay that switches 380 VAC at up to 4 A.
MP Model, 380 VAC, 4 Amp, DC Control Solid State Relay (SSR)
MP240D4-17
This MP model, 240 VAC, 4 Amp, DC Control Solid State Relay (SSR) should be used as a replacement part only.
MP Model, 240 VAC, 4 Amp, DC Control Solid State Relay (SSR), Replacement Part Only
MP240D4
The MP240D4 is a DC-controlled MP Series relay that switches 240 VAC at up to 4 A.
MP Model, 240 VAC, 4 Amp, DC Control Solid State Relay (SSR)
MP240D2
The MP240D2 is a DC-controlled MP Series relay that switches 240 VAC at up to 2 A.
MP Model, 240 VAC, 2 Amp, DC Control Solid State Relay (SSR)
MP120D4
The MP120D4 is a DC-controlled MP Series relay that switches 120 VAC at up to 4 A.
MP Model, 120 VAC, 4 Amp, DC Control Solid State Relay (SSR)
MP120D2
The MP120D2 is a DC-controlled MP Series relay that switches 120 VAC at up to 2 A.
MP Model, 120 VAC, 2 Amp, DC Control Solid State Relay (SSR)
DC60MP
The DC60MP is a DC-controlled MP Series relay that switches 60 VDC at up to 3 A.
MP Model, 60 VDC, 3 Amp, DC Control Solid State Relay (SSR)
DC200MP
The DC200MP is a DC-controlled MP Series relay that switches 200 VDC at up to 1 A.
MP Model, 200 VDC, 1 Amp, DC Control Solid State Relay (SSR)
Power Series AC Control
240A45
The 240A45 is an AC-controlled Power Series relay that switches 240 VAC at up to 45 A.
240 VAC, 45 Amp, AC Control Solid State Relay (SSR)
240A25
The 240A25 is an AC-controlled Power Series relay that switches 240 VAC at up to 25 A.
240 VAC, 25 Amp, AC Control Solid State Relay (SSR)
240A10
The 240A10 is an AC-controlled Power Series relay that switches 240 VAC at up to 10 A.
240 VAC, 10 Amp, AC Control Solid State Relay (SSR)
120A25
The 120A25 is an AC-controlled Power Series relay that switches 120 VAC at up to 25 A.
120 VAC, 25 Amp, AC Control Solid State Relay (SSR)
120A10
The 120A10 is an AC-controlled Power Series relay that switches 120 VAC at up to 10 A.
120 VAC, 10 Amp, AC Control Solid State Relay (SSR)
Power Series DC Control
SNAP-AITM
The SNAP-AITM provides two channels of analog-to-digital conversion. Each channel can be configured for -150 to +150 mV DC or -75 to +75 mV DC, or for type E, J, or K thermocouple operation. Use isolated probes for thermocouple inputs.
SNAP 2-Ch Type E, J, K Thermocouple or -150mV to +150mV Analog Input Module
SNAP-AITM-2
The SNAP-AITM-2 provides two channels of analog input with a range of -50 to +50 mV, -25 to +25 mV, or type B,C,D,G,N,T,R, or S thermocouple. Use isolated probes for thermocouple inputs. Although the two channels are not isolated from each other, the module is transformer isolated and optically isolated from other modules and devices.
SNAP 2-Ch Type B,C,D,G,N,T,R, or S Thermocouple Analog Input Module
SNAP-AIRTD
The SNAP-AIRTD provides two channels of analog temperature input. Nominal input temperature range is -200 to +850 degrees C. Input range is 0 to 400 ohms. Although the two channels are not isolated from each other, the module is transformer isolated and optically isolated from other modules and devices. Modules are factory calibrated.
SNAP 2-Ch 100-Ohm Platinum RTD Analog Temperature Input Module
SNAP-AICTD
The SNAP-AICTD provides two channels of analog temperature input from any industry-standard Integrated Circuit Temperature Device (ICTD). Simple two-wire connections are made to the pluggable terminal strip on top of the module. Although the two channels are not isolated from each other, the module is transformer isolated and optically isolated from other modules and devices.
SNAP 2-Ch Analog Temperature Input Module - ICTD
SNAP-AITM-i
The SNAP-AITM-i provides two isolated channels of analog-to-digital conversion. Each channel can be configured for -150 to +150 mV DC, or -75 to +75 mV DC, or for type E, J, or K thermocouple operation.
SNAP 2-Ch Isolated Type E,J, or K Thermocouple Analog Input Module
SNAP-ATM2-i
The SNAP-AITM2-i provides two isolated channels, each with an input range of -50 to +50 mV, -25 to +25 mV, or type B,C,D,G,N,T,R, or S thermocouple. In addition to having two channels isolated from each other, the module is also transformer isolated and optically isolated from other modules and devices.
SNAP 2-Ch Isolated Type B,C,D,G,N,T,R, or S Thermocouple Analog Input Module
SNAP-AIR40K-4
The SNAP-AIR40K-4 provides four channels of analog-to-digital conversion, ideal for thermistors used in HVAC applications or for reading the resistance of potentiometer input. Default range is 0-40 K Ohms; the module can also be configured for 0-20 K, 0-10 K, or 0-5 K Ohms. Resistance probes must be isolated from each other.
SNAP 4-Ch Analog Thermistor Input Module
SNAP-AITM-8
The SNAP-AITM-8 provides eight channels of thermocouple or millivolt input. Each channel can be individually configured to accept a type B, C, D, E, G, J, K, N, R, S, or T thermocouple or a -75 to + 75 mV, -50 to +50 mV, or -25 to +25 mV input.
SNAP 8-Ch Type B, C, D, E, G, J, K, N, R, S, or T Thermocouple or +/-75, +/-50, or +/-25 mV Analog Input Module
SNAP-AICTD-8
The SNAP-AICTD-8 provides eight channels of analog temperature input from any industry-standard Integrated Circuit Temperature Device (ICTD). Simple two-wire connections are made to standard connectors on top of the module. Although the eight channels are not isolated from each other, the module is transformer isolated and optically isolated from other modules and devices.
SNAP 8-Ch Analog Temperature Input Module - ICTD
SNAP-AIRTD-10
The SNAP-AIRTD-10 provides two channels of analog temperature input. Nominal input range is -180 to +260 degrees C. Although the two channels are not isolated from each other, the module is transformer isolated and optically isolated from other modules and devices. Modules are factory calibrated.
SNAP 2-Ch 10-Ohm Copper RTD Analog Temperature Input
SNAP-AITM-4i
The versatile SNAP-AITM-4i module provides four channels of analog input with an input range of ±150 mV, ±75 mV, ±50 mV, ±25 mV, or Type B, C, D, E, G, J, K, N, R, S, or T thermocouple, and each channel can be individually configured.
SNAP 4-Ch Isolated Type B, C, D, E, G, J, K, N, R, S, or T Thermocouple or or +/-150, +/-75, +/-50, or +/-25 mV Analog Input Module
SNAP-AIRTD-1K
The SNAP-AIRTD-1K provides two channels of analog temperature input. Nominal input temperature range is -200 to +850 degrees C. Input range is 0-4000 ohms. Although the two channels are not isolated from each other, the module is transformer isolated and optically isolated from other modules and devices. Modules are factory calibrated.
SNAP 2-channel 1000 Ohm Platinum RTD Analog Temperature Input Module
SNAP-AIR400K-8
The SNAP-AIR400K-8 module has eight channels of analog to digital conversion that convert resistance to temperature or to ohms. The module is ideal for NTC thermistors commonly used in HVAC, refrigeration, and process control applications. It may also be used with PTC thermistors in resistance sensing applications.
SNAP 8-Ch Analog Resistor/thermistor Input, 400 K Ohms
SNAP-AIRTD-8U
The SNAP-AIRTD-8U analog input module provides 8 input channels, each individually software configurable. This module is commonly used for 3-wire RTD temperature inputs but is also suited to high-resolution resistance measurements. It features open circuit detection if any wire breaks.
SNAP 8-Ch Multifunction RTD/Resistance Analog Temperature Input Module
Power Series DC Control
240Di10
The 240Di10 is a DC-controlled Power Series relay that switches 240 VAC at up to 10 A. It includes a built-in LED to indicate operation.
240 VAC, 10 Amp, DC Control Solid State Relay (SSR), with LED Indicator
240Di25
The 240Di25 is a DC-controlled Power Series relay that switches 240 VAC at up to 25 A. It includes a built-in LED to indicate operation.
240 VAC, 25 Amp, DC Control Solid State Relay (SSR) with LED Indicator
240Di45
The 240Di45 is a DC-controlled Power Series relay that switches 240 VAC at up to 45 A. It includes a built-in LED to indicate operation.
240 VAC, 45 Amp, DC Control Solid State Relay (SSR) with LED Indicator
575Di45-12
The 575Di45-12 is a DC-controlled Power Series relay that switches 575 VAC at up to 45 A. This SSR is transient proof and includes a built-in LED to indicate operation.
575 VAC, 45 Amp, DC Control Solid State Relay (SSR) with LED Indicator, Transient Proof
575D45-12
The 575D45-12 is a DC-controlled Power Series relay that switches 575 VAC at up to 45 A. This SSR is transient proof.
575 VAC, 45 Amp, DC Control Solid State Relay (SSR), Transient Proof
575D15-12
The 575D15-12 is a DC-controlled Power Series relay that switches 575 VAC at up to 15 A. This SSR is transient proof.
575 VAC, 15 Amp, DC Control Solid State Relay (SSR), Transient Proof
480D45-12
The 480D45-12 is a DC-controlled Power Series relay that switches 480 VAC at up to 45 A. This SSR is transient proof.
480 VAC, 45 Amp, DC Control Solid State Relay (SSR), Transient Proof
480D25-12
The 480D25-12 is a DC-controlled Power Series relay that switches 480 VAC at up to 25 A. This SSR is transient proof.
480 VAC, 25 Amp, DC Control Solid State Relay (SSR), Transient Proof
480D15-12
The 480D15-12 is a DC-controlled Power Series relay that switches 480 VAC at up to 15 A. This SSR is transient proof.
480 VAC, 15 Amp, DC Control Solid State Relay (SSR), Transient Proof
480D10-12
The 480D10-12 is a DC-controlled Power Series relay that switches 480 VAC at up to 10 A. This SSR is transient proof.
480 VAC, 10 Amp, DC Control Solid State Relay (SSR), Transient Proof
380D45
The 380D45 is a DC-controlled Power Series relay that switches 380 VAC at up to 45 A.
380 VAC, 45 Amp, DC Control Solid State Relay (SSR)
380D25
The 380D25 is a DC-controlled Power Series relay that switches 380 VAC at up to 25 A.
380 VAC, 25 Amp, DC Control Solid State Relay (SSR)
240D45
The 240D45 is a DC-controlled Power Series relay that switches 240 VAC at up to 45 A.
240 VAC, 45 Amp, DC Control Solid State Relay (SSR)
240D3
The 240D3 is a DC-controlled Power Series relay that switches 240 VAC at up to 3 A.
240 VAC, 3 Amp, DC Control Solid State Relay (SSR)
240D25-17
This 240 VAC, 25Amp, DC Control Solid State Relay (SSR) should be used as a replacement part only.
240 VAC, 25 Amp, DC Control Solid State Relay (SSR), Replacement Part Only
240D45-17
This 240 VAC, 45 Amp, DC Control Solid State Relay (SSR) should be used as a replacement part only.
380 VAC, 25 Amp, DC Control Solid State Relay (SSR)
240D10-17
This 240 VAC, 10 Amp, DC Control Solid State Relay (SSR) should be used as a replacement part only.
240 VAC, 10 Amp, DC Control Solid State Relay (SSR), Replacement Part Only
240D10
The 240D10 is a DC-controlled Power Series relay that switches 240 VAC at up to 10 A.
240 VAC, 10 Amp, DC Control Solid State Relay (SSR)
120D45
The 120D45 is a DC-controlled Power Series relay that switches 120 VAC at up to 45 A.
120 VAC, 45 Amp, DC Control Solid State Relay (SSR)
120D3
The 120D3 is a DC-controlled Power Series relay that switches 120 VAC at up to 3 A.
120 VAC, 3 Amp, DC Control Solid State Relay (SSR)
120D25
The 120D25 is a DC-controlled Power Series relay that switches 120 VAC at up to 25 A.
120 VAC, 25 Amp, DC Control Solid State Relay (SSR)
120D10
The 120D10 is a DC-controlled Power Series relay that switches 120 VAC at up to 10 A.
120 VAC, 10 Amp, DC Control Solid State Relay (SSR)
DC60S5
The DC60S5 is a DC-controlled Power Series relay that switches 60 VDC at up to 5 A.
60 VDC, 5 Amp, DC Control Solid State Relay (SSR)
DC60S3
The DC60S3 is a DC-controlled Power Series relay that switches 60 VDC at up to 3 A.
60 VDC, 3 Amp, DC Control Solid State Relay (SSR)
240D25
The 240D25 is a DC-controlled Power Series relay that switches 240 VAC at up to 25 A.
240 VAC, 25 Amp, DC Control Solid State Relay (SSR)
Power Series Accessories
SAFETY COVER
The Opto 22 solid state relay (SSR) safety cover for Opto 22 Power Series SSRs reduces the chance of accidental contact with relay terminals, while providing access holes for test instrumentation.
Solid State Relay (SSR) Cover for Power Series Standard Model
SSR-HS
Custom designed for the Power Series SSRs, the SSR-HS heatsink provides excellent heat dissipation when mounted to the SSR with a matching thermal conductive pad, which is used in place of silicon grease. One thermal pad is included with the heatsink. Also includes a DIN-rail adapter.
Solid State Relay (SSR) Heatsink for Power Series Standard Model
SSR-Thermopad
Used instead of silicon grease, this thermal conductive pad is custom designed for the Power Series SSR heatsink (SSR-HS). Pack of 10.
Thermal conductive pad for Power Series SSR heatsink, 10 pack
Z Series
Z240D10-17
This Z Model, 240 VAC, 10 Amp, DC Control Solid State Relay (SSR) should be used as a replacement part only.
Z Model, 240 VAC, 10 Amp, DC Control Solid State Relay (SSR), Replacement Part Only
Z240D10
The Z240D10 is a DC-controlled relay that switches 240 VAC at up to 10 A.
Z Model, 240 VAC, 10 Amp, DC Control Solid State Relay (SSR)
Z120D10
The Z120D10 is a DC-controlled relay that switches 120 VAC at up to 10 A.
